Boom Gates

A boom barrier, also known as a boom gate, is a bar, or pole pivoted to allow the boom to block vehicular access through a controlled point. Typically the tip of a boom gate rises in a vertical arc to a near vertical position. Boom gates are often counter weighted, so the pole is easily tipped. Boom gates are often paired either end to end, or offset appropriately to block traffic in both directions. KELRYAN have been installing Boom gates for over 15 years in Sydney, Wollongong, Sutherland, Campbelltown, Newcastle, Canberra, Nowra & Ulladulla.

Some boom gates also have a second arm which hangs 300 to 400 mm below the upper arm when lowered, to increase approach visibility, and which hangs on links so it lies flat with the main boom as the barrier is raised. Some barriers also feature a pivot roughly half way, where as the barrier is raised, the outermost half remains horizontal, with the barrier resembling an upside-down L when raised.

There are various technologies for an automatic boom barrier. One of them is electro-mechanical, which is widely used due to its reliability. The other technologies are often manufacturer specific. These electro-mechanical device comes with 24VDC drive unit which can run continuously without generating heat, so electro-mechanical boom barriers can be operated continuously and in an intensive duty cycle.

Boom gates are typically found at Level crossings, drawbridges, parking facilities, checkpoints and entrances to restricted areas. They are also the usual method for controlling passage through toll booths, and can also be found on some freeway entrance ramps which are automatically controlled to drop to restrict traffic in the event of accident clean up or road closures without the need to dispatch road workers or law enforcement to use a vehicle to block the way. Some boom gates are automatic and powered, others are manually operated. Manual gates are sometimes hung in the manner of a normal gate (i.e. hinged horizontally). In some places, boom gates are installed across suburban streets as a traffic calming measure, preventing through traffic, while allowing authorised vehicles such as emergency services and buses to take advantage of the shorter and more direct route.
